1 Introduction
The In-Sight™ Strobe Light Adapter (Cognex P/N CLA-2000-00) is designed for use
with an In-Sight 2000 or 3000 system and most Cognex Light Modules (CLMs),
including the Ring Light (P/N CLM-4236), the Dome Light (P/N CLM-7248), and the
Spot Light (CLM-2420). This system can illuminate a part, image it at high speed, and
acquire the “frozen” image.
The Strobe Light Adapter (Figure 1-1) includes an integrated power cable and a Strobe
Control Cable.
Figure 1-1: In-Sight Light Adapter Controls and Connections
This document presents information related to installing and using the In-Sight Strobe
Light Adapter in the following sections:
G Installation
G Troubleshooting
G Specifications
