CognitiveTPG DLXi - Default Printer Settings

28
The DLXi ships with the following default settings:
Parameter Default Setting
Programming Language CPL - Cognitive Programming Language
Speed 5 ips (127 mm/s)
Label Width 2” Models: 220 (2.2” or 56 mm)
4” Models: 409 (4.09” or 104 mm)
Label Length Measure label (automatically measures and
sets label length at power up)
Indexing Type Gap
Reference Point 0,0 (upper left corner)
Auto Top of Form On
Enable Label Present O
Advance Label 75 (0.75” or 19 mm)
Retract Label 75 (0.75” or 19 mm)
Delay Time (Retract Label) 0 seconds
Serial Port Settings
(serial port printers only)
9600 bps, 8 bit data, 1 stop bit, no parity
(DTE conguration - use null-modem cable)
Settings below only apply to printers with Ethernet
Printer IP Address 10.0.0.12
Net Mask 255.255.255.255
Gateway 0.0.0.0
DHCP On
LPD On
RTEL On
RTEL Port Number 9100
