Cole Parmer Masterflex B/T Rapid-Load User Manual

B/T
®
RAPID-LOAD
®
Peristaltic Pumps and Drive Operating Manual 1-1Cole-Parmer
Section 1 Introduction
This manual provides information for installing, operating and servicing
the following models of MASTERFLEX
®
B/T
®
RAPID-LOAD
®
Peristaltic
Pumps and Drives.
MODEL TYPE
77111-00 Fixed Speed w/TEFC, 115V AC @ 60 Hz
77111-07 Fixed Speed w/TEFC, 230V AC @ 50 Hz
77111-10 Controller Only 115VAC for 77111-40
77111-12 Drive Only 115VAC for 77111-40
77111-15 Controller Only 230VAC for 77111-47
77111-17 Drive Only 230VAC for 77111-47
77111-40 Modular Drive , Digital 115V AC system.
77111-47 Modular Drive , Digital 230V AC system.
77111-50 Drive Only NEMA56C mount less motor
77111-55 Drive Only IEC72 mount less motor
77111-60 Modular Drive, Analog 115V AC system
77111-67 Modular Drive, Analog 230V AC system
77111-80 Air-Powered Variable Occlusion Peristaltic Pump and Drive.
The unique design of these peristaltic pumps provides a greatly simplified
means for rapid loading and changing of tubing. In addition, the following
features are incorporated:
Pumps up to 10 GPM (37 LPM).
Uses continuous tubing to ensure a sanitary and non-contaminating
system.
Fluid contacts only the tubing.
Handles wide range of viscosities.
Several different sizes and formulations of tubing can be used.

Cole Parmer Masterflex B/T Rapid-Load Specifications

General

Brand	Cole Parmer
Model	Masterflex B/T Rapid-Load
Category	Water Pump
Language	English
