Cole Parmer Masterflex B/T Rapid-Load User Manual

B/T
®
RAPID-LOAD
®
Peristaltic Pumps and Drive Operating Manual 2-1Cole-Parmer
Section 2 Installation and Setup
These units should be placed on a flat surface such as a floor, bench or
table and should be near an electrical power source. Be sure to check data
plate for proper voltage rating(s).
Figure 2-1. Pump Mounting Dimensions, applies to all Pump Systems.
PUMP MOUNTING
DIMENSIONS
(All Models)
27.0
(685.80)
15.8
(400.05)
.5
(12.70)
14.8
374.65
25.5
(647.70)
12.8
(323.85)
.3 (6.35)
6
X
.5 (13.49)
.8
(19.05)
CLEARANCE FOR 1/4 IN SCREW
Figure 2-2. Control Box Mounting Dimensions 77111-10, 77111-15, 77111-40
and 77111-47.
CONTROL BOX
MOUNTING
DIMENSIONS
(Digital Models Only)
