TECHNICAL DESCRIPTION ULTRA 85BS
Working width mm 910
Lateral movement of base mm 100
Work capacity sq.m/h 5500
Cylindrical brushes (2) Ø xl mm 210x867
Cylindrical brushes rpm rpm 630
Pressure on cylindrical brushes kg max 80
Maximum specific pressure Grs/sq.cm 70
Cylindrical brush motors W 2x1300
Cylindrical brush motor V 36
Traction motor W 1500
Traction motor V 36
Traction wheel Ø mm 300
Movement speed km/h 0÷6.5
Maximum gradient with full load 10%
Suction motor V 36
Suction motor W 670
Suction vacuum mbar 190
Rear elastic wheels Ø mm 370x105
Solution tank l 200
Recovery tank l 215
Steering diameter mm 2500
Machine length mm 2030
Machine height mm 1560
Machine width (with side bars) mm 1060
Batteries V/Ah max 36/360
Battery weight kg max 430
Machine weight (empty and without batteries) kg 630
Noise level (in compliance with IEC 704/1) dB (A) 62.6
Hand vibration level m/s
2
2.99
Body vibration level m/s
2
0.96
