Bulk 2 blink / s
– led off
Recovery
1
5 blink / s
– led off
State
Diagnostic
indicator
Fault
indicator
Reverse polarity or high battery voltage 1 blink / pause
– led on
Battery not connected (Power supply mode) 2 blink / pause
– led on
Cell in short circuit 3 blink / pause
– led on
Bad battery: Internal impedance or battery connection problem (Life
Test result)
5 blink / pause
– led on
Life test not possible 6 blink / pause
– led on
Internal fault 9 blink / pause
– led on
Charger diagnosis
Battery type selection
InteliCharger 240 24 is completely automatic charger suitable to charge most battery types. Charger can charge
open lead acid, sealed lead acid, gel and NiCd–NiMH batteries.
IMPORTANT: Power off the charger before setting the jumper.
Battery
type
Jumper
position
Standard Bulk, Absorption, Float
cell / battery voltage
Bulk, Absorption cell / battery
voltage in Boost mode
Open
lead
2.23 V /26.76 V 2.40 V / 28.80 V
Sealed
lead
2.25 V / 27.00 V 2.40 V / 28.80 V
Gel 2.30 V / 27.60 V 2.40 V / 28.80 V
NiCd–
NiMH
N/A N/A
Note: For NiCd–NiMH batteries end-of-charge is determined by negative ΔV detection of battery voltage (-5
mV/cell). If no negative ΔV but only a “flat” profile is detected fast charge is terminated after 10 min. General
end-of-charge timeout set to 16 h. Float charge current is regulated at 10% of max current corresponding to
trimmer position. In order to detect end-of-charge negative ΔV, charging current must be set at least at 30% of
nominal battery capacity (0.3 C). With lower values of charging current negative ΔV detection is not
guaranteed.
Boost charge selection
Set jumper on position 5 to enable boost charging.Using this option charging voltage in Bulk
and Absorption stage is adjusted to 28.80 V (2.40 V / cell).

ComAp InteliCharger 240 24 Specifications

General

Brand	ComAp
Model	InteliCharger 240 24
Category	Battery Charger
Language	English
