InteliCharger 240 24 Reference Guide
8
Note: See Detailed description (page 9) for charger configuration details.
3.3 Wires parameters
Use wires with following parameters for all connection type (Input / Output / Signal):
Solid
[mm
2
]
Stranded
[mm
2
]
AWG
[–]
Torque
[Nm]
Stripping length
[mm]
0.2–2.5 0.2–2.5 24–14 0.5–0.6 7
Note: The connection is made by the screw type 2.5 mm
2
terminal blocks. Use only copper cables that are
designed for operating temperatures higher than 75 °C.
