7 Technical data
Nominal input voltage 115 / 230V
AC
Input voltage range 90–135 / 180–305V
AC
Inrush current (V
N
and I
N
load) ≤ 16 A, ≤ 5ms
Frequency 47–63 Hz ± 6 %
Input current (115 / 230 V
AC
) 3.3 / 2.2 A
Internal fuse 6.3 A
Recommended external fuse 16 A (MCB curve B)
Input data
Output V
DC
/ I
N
24 V
DC
/ 10A
Efficiency (50 % of I
N
) ≥ 88 %
Ripple voltage ≤ 80 mV
PP
Output data
Short–circuit protection Yes
Overload protection Yes
Overvoltage output protection Yes
Reverse battery polarity protection Yes
Detection of element in short–circuit Yes
Thermal protection Yes
Protection
Operating ambient temperature range -25–+70 °C
Storage ambient temperature range -40–+85 °C
Max humidity (25 °C) 95 %
IP protection class (EN/IEC 60529) IP20
Reliability (MTBF IEC 61709) > 300000 h
Protection class (with PE connected)
I
Dimension (w×h×d) 112 mm × 114 mm × 136 mm
Weight approx. 0.85 kg
General data
