ComAp InteliLite MRS10

Range: 0 – 180 s
AnlInp3 level1 [ ]
Warning threshold level for ANALOG INPUT 3
Step: 1 %
Range: AnlInp3 level2 – 10000
AnlInp3 level2 [ ]
Shutdown threshold level for ANALOG INPUT 3
Step: 1 %
Range: -100 – AnlInp3 level1
AnlInp3 del [s]
Delay for ANALOG INPUT 3
Step: 1 s
Range: 0 – 180 s
Batt undervolt [V]
Warning threshold for low battery voltage.
Step: 0,1 V
Range: 8V – Batt overvolt
Batt overvolt [V]
Warning threshold for high battery voltage.
Step: 0,1 V
Range: Batt undervolt – 40 V
Batt volt del [s]
Delay for low battery voltage alarm.
Step: 1s
Range: 0 – 600 s
NextServTime [h]
Counts down when engine running. If reaches zero, an alarm appears.
Step: 1h
Range: 0 – 65535h
Gener protect
Hint:
All electric protections when activated result in shutdown.
Overload [%]
Threshold for generator overload (in % of Nominal power)
Step: 1% of Nominal power
Range: 0 – 200%
Overload del [s]
Delay for generator overload alarm.
Step: 0.1s
Range: 0 – 60.0 s
Ishort [ % ]
Shutdown occurs when short circuit limit Ishort limit is reached.
Step: 1 % of Nominal current
Range: 100 - 500 %
InteliLite – MRS10/11/15/16, SW version 2.2, ©ComAp – November 2004 33
