ComAp InteliLite MRS10

Dimensions
IL-CU
iL
185 (7,3")
170 (8,87")
4 2 , 5 ( 1 , 7 " )
4 5 ( 1 , 8 " )
1
2
1
2
1 3 0 ( 5 , 1 " )
1 2 3 ( 4 , 8 " )
1 1 3 ( 4 , 4 " )
1
Cutout
for InteliLite
113 x 175 mm
(4.4 x 6,9“)
Only for service purpose
IL-MRS 10, 11
IL-MRS 15, 16
AT-LINK-CONV
InteliLite MRS 15
iL
185 (7,3")
170 (8,87")
4 2 , 5 ( 1 , 7 " )
4 5 ( 1 , 8 " )
~ 1 1 0 ( 4 , 3 " )
2
1
2
RS 232 Cable
Extension module via CAN bus
1 3 0 ( 5 , 1 " )
1 2 3 ( 4 , 8 " )
1 1 3 ( 4 , 4 " )
1
