Starting POil [Bar]
When reached controller stops cranking (starter goes OFF).
Step: 0,1 bar
Range: -10,0 – 1000,0
Hint:
There are three conditions for stop cranking: Starting RPM, StartingPOil and D+ (when enabled).
Starter goes off when any of these conditions is vaid.
Prestart time [s]
Time of closing of the PRE-START output prior to the engine start.
Set to zero if you want to leave the output PRE-START open.
Step: 1s
Range: 0 – 600 s
MaxCrank time [s]
Maximum time limit of cranking.
Step: 1s
Range: 1 – 60 s
CrnkFail pause [s]
Pause between crank attempts.
Step: 1s
Range: 5 – 60 s
Crank attemps [-]
Max number of crank attempts.
Step: 1
Range: 1 – 10
Idle time [s]
Idle time delay starts when RPM exceeds Start RPM . Start fail is detected when during Idle state
RPM decreases below 2.
During the Idle time timer running the binary output IDLE/NOMINAL is opened, when it elapses the
IDLE/NOMINAL output closes. Binary output IDLE/NOMINAL opens during Cooling period again.
Step: 1 s
Range: 0 – 600 s
Start RPM
R
P
M
BO Starter
BO IDLE/RATED
RPM = 2
R
P
M
Start Fail
Idle time Min stab time
Electric protections
active
Hint:
If the IDLE function not supported on the governor, set the Idle time nevertheless to minimum 5s to
avoid Underspeed possibly caused by instability of the engine short after start.
InteliLite – MRS10/11/15/16, SW version 2.2, ©ComAp – November 2004 30
