InteliLite

– AMF20/25, SW version 2.2, ©ComAp – September 2014 25

IL-NT-AMF-2.2-Reference Guide.pdf

Recommended Wiring

AMF – Wiring Diagram

Hint:

MCB and GCB is recommended to be mechanically interlocked.

It is possible to start Volvo and Scania engines via CAN bus. See Engines started via CAN bus.

Table of Contents2
General Guidelines5
- What Describes this Manual5
- Warnings5
- Symbols5
- Text6
- Dangerous Voltage6
- Adjust Set Points6
General Description7
- Description of the Controller System (with All Options)7
- What Is in the Package7
- IL-NT RS232 Communication Plug-In Card7
- IL-NT RS232-485 Communication Plug-In Card11
- IL-NT S-USB Service USB Communication Plug-In Card12
- IB-Lite Ethernet Communication Plug-In Card13
- IL-NT-GPRS GSM and GPRS Plug-In Modem14
- IL-NT AOUT8 Gauge Driver Module15
- IL-NT BIO8 Hybrid Binary Input/Output Module17
- IC-Nt Ct-Bio718
- IL-NT RD Remote Display Software18
- Remote Annunciator IGL - RA1518
- IG IOM/PTM Module19
- IG-IB Internet Bridge20
- Internetbridge-NT21
IL-NT Terminals22
- IL-NT Terminals and Front Face22
Installation23
- Mounting23
- Dimensions24
Recommended Wiring25
- AMF - Wiring Diagram25
Contactors (Set Point MCB Logic = "CLOSE-OFF")26
ATS with Two Stable Positions (Set Point MCB Logic = "CLOSE-ON")26
Stand-By Applications26
ATS with Three Stable Positions (Set Point MCB Logic = "CLOSE-OFF")27
- Dual Mutual Standby (Dual AMF) Application27
Getting Started30
- How to Install30
- Current Measurement34
- Earth Fault Measurement (Module)36
- Voltage Measurement and Generator Connection Types37
- Analog Inputs40
- Binary Inputs and Outputs46
- Recommended CAN/RS485 Connection47
- Extension Modules (CAN Bus) Connection49
Inputs and Outputs50
- Binary Inputs IL-NT - Default50
- Binary Inputs - List50
- Binary Outputs IL-NT - Default54
- Binary Outputs - List55
- Analog Inputs65
- Analog Outputs65
Setpoints66
- Password66
- Basic Settings66
- Comms Settings70
- Engine Params73
- Engine Protect77
- Gener Protect79
- AMF Settings81
- Extension I/O85
- Date/Time85
- Sensors Spec87
- SMS/E-Mail87
- Alternate Cfg89
- Earthfaultprot90
ECU-Controlled Engine Support92
- Identifying Configured ECU93
- Values Read from ECU93
- Diagnostic Messages Read from ECU94
- Analog Inputs94
- Connection Description95
Sensor Specification98
- Background of the Sensor Calibration98
- Default Sensor Curves98
Function Description99
- OFF Mode99
- MAN Mode99
- AUT Mode101
- TEST Mode102
- Circuit Breakers Timing102
Alarm Management105
- Sensor Fail (FLS)105
- Warning (WRN)105
- Breaker Open and Cooling (BOC)105
- Shut down (SD)106
- Mains Failure (MF)106
- Voltage Phase Sequence Detection106
Gen-Set Operation States108
- List of Possible Events110
- History File112
Init Screens115
- Customer Logo Screen115
- Firmware Init Screen115
- Language Screen115
- User Interface Screen115
Remote Control and Data Logging116
- PC Software - Liteedit116
- Direct Cable Connection116
- Modem Connection117
- Internet Connection118
- IB-Lite119
- Il-Nt-Gprs120
- Internetbridge-NT125
- Ig-Ib125
- Airgate125
- Locate125
- SNMP Protocol125
- Modbus Protocol127
- Communication Object List127
- IL-NT-RD Remote Display Software132
Maintenance137
- Backup Battery Replacement137
Technical Data139
- Inputs/Outputs Overview139
- Generator Protections139
- Language Support139
- Power Supply140
- Operating Conditions140
- Low Temperature Modification140
- Dimensions and Weight141
- Mains and Generator141
- Binary Inputs and Outputs141
- Analog Inputs142
- Speed Pick-Up Input142
- D+ Function142
- CAN Bus Interface142
- IL-NT RS232 Interface (Optional Card)143
- IL-NT RS232-485 Interface (Optional Card)143
- IL-NT S-USB Interface (Optional Card)143
- IL-NT AOUT8 Interface (Optional Card)143
- IC-NT CT-BIO7 Interface (Optional Card)144
- IL-NT BIO8 Interface (Optional Card)144
- Igs-Ptm145
- Igl-Ra15145
- Ig-Ib145
