Appendix A – Gateway Connection via RJ45 Cross-Over Ethernet Cable
1. Set up your computer temporarily with a xed IP address using the instructions given in Appendix B - Setting a
Fixed IP Address.
2. Connect the cross-over Ethernet cable between computer and RJ45 jack on the Gateway.
3. Congure the RF500A Gateway as in Gateway Commissioning. {Page 17}
4. Remove the cross-over Ethernet cable after the Gateway has reset. (See Gateway Reset {Page 11})
5. Using Appendix B - Setting a Fixed IP Address as a guide, restore the computer network settings back to as
existed previously.
6. Connect both the PC and RF500 Gateway to the LAN using regular Ethernet patch leads.
7. Verify that a connection can be made to the Gateway by following the steps in “Viewing the Gateway Login
Page” {Page 19} but using the newly congured IP Address instead of 192.168.25.220.
