MicroBlaster MB1000 Section 3: Using the MicroBlaster
Comco Inc. 3-9 Issue Date: July 2016
Table 3 - 4: Nozzle Chart
[1]
HIGH PERFORMANCE NOZZLES (ROUND) - MB1520
Part
No.
Holder
Color
Size
I.D.
Size
I.D. mm
Tip
O.D.
Tank Orifice
Abrasive
(Microns)
Comments
-18
Violet
.018
0.4
.046
.018 - .025
20 - 50
Medium Cuts
-30
Green
.030
0.7
.074
.025 - .040
20 - 100
Large Cuts
-46
Yellow
.046
1.1
.120
.025 - .040
25 - 200
Large Cuts
-60
Red
.060
1.5
.125
.030 - .040
25 - 300
Large Cuts
STANDARD ROUND NOZZLES - P/N MB1500
-10
Silver
.015
0.3
.046
.018 - .025
10 - 25
Small Cuts/Holes
-24
Violet
.018
0.4
.046
.018 - .025
20 - 50
Medium Cuts
-27
[2]
Black
.018
0.4
.034
.018 - .025
20 - 50
Medium Cuts
-37
Orange
.025
0.6
.061
.018 - .030
20 - 50
Medium Cuts
-11
Green
.030
0.7
.074
.025 - .040
20 - 100
Large Cuts
-29
Yellow
.046
1.1
.120
.025 - .040
25 - 200
Large Cuts
STANDARD RECTANGULAR NOZZLES - P/N MB1500
-26
Orange
.008x.020
0.2x0.5
.046
.018 - .025
10 - 25
Small Cuts
-12
Blue
.008x.040
0.2x1.0
.074
.018 - .025
10 - 50
Fan, Small Cuts
-19
Red
.008x.060
0.2x1.5
.095
.018 - .025
10 - 50
Fan, Medium Cuts
-20
Silver
.008x.080
0.2x2.0
.120
.018 - .025
10 - 50
Fan, Medium Cuts
-22
Olive
.008x.125
0.2x3.1
.175
.018 - .040
10 - 50
Fan, Large Cuts
-23
Black
.008x.150
0.2x3.8
.195
.018 - .040
10 - 50
Fan, Large Cuts
-32
Blue
.012x.150
0.3x3.8
.195
.025 - .040
20 - 80
Large Cuts
ROUND NOZZLES W/EXTENDED CARBIDES - MB1503 (1.5" LONG)
-1
Violet
.018
0.4
.066
.018 - .025
20 - 50
Medium Cuts
-2
Green
.030
0.7
.094
.025 - .040
20 - 100
Large Cuts
-3
Yellow
.046
1.1
.157
.025 - .040
25 - 200
Large Cuts
90° ANGLE NOZZLES - MB1501
-25
Violet
.018
0.4
.046
[3]
.018 - .025
20 - 50
Medium Cuts
-14
Green
.030
0.7
.074
[3]
.025 - .040
20 - 100
Large Cuts
-28
Yellow
.046
1.1
.120
[3]
.025 - .040
25 - 200
Large Cuts
-15
Blue
.008x.040
.02x1.0
.074
[3]
.018 - .025
10 - 50
Fan, Small cuts
[1] Dimensions are in inches unless noted otherwise.
[2] Used for special circumstances only.
[3] Overall width is approximately 1/2”.
 Standard Nozzle thread configuration is 10-32.
