Comco MicroBlaster MB1000 - MAJOR ASSEMBLIES AND PRINCIPAL PARTS

Appendix A: Assemblies, Components, and Parts MicroBlaster MB1000
Comco Inc. A-2 Issue Date: July 2016
MAJOR ASSEMBLIES AND PRINCIPAL PARTS
PART NUMBER DESCRIPTION QTY.
MB1409-40
[1]
Orifice, Tank, 0.040" 1
MB1568 Cover, Tank, Assy. 1
 MB1145 Flapper Assy 1
 ST5022 O-ring, Cover Seal 1
 ST5624 O-ring, Flapper Seal 1
MB1083-3 Handpiece, Nozzle, Assy. 1
 MB1012-6 Tube, Handpiece 1
 MB1230-1 Nose, Handpiece 1
 MB1233 Hose, Abrasive 6 ft
MB1125 Cover, Standard MicroBlaster 1
MB1489-1
[2]
Pinch, Vent Assy. 1
 MB1050-2 Plunger, Pinch 1
 MB1282 Tube, Pinch 1
 MB1384-1 Bracket, Valve 1
 ST4003 Vent, Breather 2
 ST4010 Elbow, 1/4T x 1/8P 1
 ST4012 Tube, 1/4 OD, x .040 Wall 1
 ST4144 Elbow, 1/4T, 1/8MPT 2
 ST6081 Cylinder, 1-1/16 1
 ST6277-1
[2]
Valve, 3-Way, NC 1
MB1198-9
[3]
Valve, Air, Assy. 115VAC 1
 ST6013-1
[3]
Valve, Sol, 2-way, N.C., 115V 1
 ST4006 Connector, 1/4T x 1/8P 1
 ST4029 Coupler, 1/8" P 1
 ST4049 Nipple, 1/8" P 1
 ST4166 Connector,1/4T x 1/8 MPT, Push-In 1
MB1233 Hose, Abrasive 6 ft.
[1]
Tank Orifice size may be changed by Sales Order.
[2]
230V Assy is MB1489-2; Valve is ST6277-2
[3]
230V Assy is MB1198-10; Valve is ST6013-5
