MicroBlaster MB1000 Appendix A: Assemblies, Components, and Parts
Comco Inc. A-3 Issue Date: July 2016
MAJOR ASSEMBLIES AND PRINCIPAL PARTS (cont’d)
PART NUMBER DESCRIPTION QTY.
MB1290-7
[3]
Modulator, Air, Assy, 115VAC 1
 MB1301-2 Housing, Modulator, Assy 1
► MB1294 Core, Modulator 1
► MB1307 Nose, Modulator, Assy 1
► MB1482 Body, Modulator, MB 1
► ST4006 Connector, 1/4T x 1/8P 1
 MB1287 Yoke, Coil 1
 MB1310-1
[3]
Coil, Modulator, 115V 1
 ST1006 Nut, 9/16-18 1
 ST1021 Washer, Steel, 9/16 x 1-3/8 1
MB1300-5
[4]
Pinch, Abrasive, Assy., 115VAC 1
 MB1050-2 Plunger, Pinch 1
 MB1282 Tube, Pinch 1
 MB1384-1 Bracket, Pinch 1
 ST4003 Vent, Breather 2
 ST4010 Elbow, 1/4T x 1/8P 1
 ST6003-1
[4]
Valve, Sol., 3-way, 115V 1
 ST6231 Valve, Flow Control 1
 ST6081 Cylinder, 1-1/16 1
MB1396 Knob, Assy. 1
MB1397-1 Powder Adjustment Assy. 1
[3]
230V Assy is MB1290-8, Coil is MB1310-2
[4]
230V Assy is MB1300-6, Coil is ST6003-5
