Comelit 1622 - External Unit Relay for Lock-Release and Actuator Control; Door Open Indication Variant

17
Using the external unit relay on lock-release or actuator control
Door open indication use variant
1595
+
-
120-230V
Only for use in systems with a single external unit without switching devices Art. 1224A, Art. 1424.
N.C. contact for DOOR OPEN indication. The LED for the following internal units flashes: Art. 2610 with R.I. 008, Art.
2619 with R.I. 000.
SB/DO
Local lock release button.
E
S
NC NO
D
N
G
R
P
R
T
E
-
V V
+
M
O
C
D
O
L L
1622
12V/24V
AC-DC
J1
J2
33436
J1
J2
10A MAX
230 V
120-230 V
-
+
1595
+
-
SB/RTNP
f “C.NC.NO relay activation on actuator command: 2 sec”
f Set the dip switches permanently as shown in the figure (Dip switch ON 8, Dip switch
OFF 1,2,3,4,5,6,7)
Applies to Art. 1622L.
Applies to Art. 1622 with R.I. 038 or greater
