19
device positioned underneath the LPin-LPin line of
switching device Art. 1424 as LP-IN.
For the PARALLEL switchboard, switching to NIGHT
and the DAY/NIGHT AUTOMATIC function is not
possible (see ”I3 - Day/night automatic mode” ).
A P should appear on the standby screen of the two
switchboards, indicating that the switchboard is
configured in parallel, in addition to the fixed icon .
3- If there are 2 main or secondary switchboards serving the
same riser, the SERIES configuration implies that only 1
of the 2 can be operative (MASTER switchboard), while
the other is deactivated (SLAVE switchboard) (see SBTOP
audio/video system).
f Configure both switchboards as SERIES and the
active switchboard will, from time to time, be the one
set as MASTER. To change a switchboard from
MASTER to SLAVE and vice-versa, see “U21 How to
ACTIVATE (MASTER) or DEACTIVATE (SLAVE) the main
switchboards” page 13.
An S should appear on the standby screen of the two
switchboards, indicating that the switchboard is
configured in series, in addition to the fixed icon
.
CAUTION!
» if
flashes, it is indicating that the 2 switchboards are
not communicating correctly.
» if the icon ! appears, there is a configuration problem
with the 2 switchboards (e.g. both set as MASTER
or SLAVE, LP-IN or LS-IN, or one is SERIES and the
other PARALLEL).
» If, in a Simplebus TOP system (with switching devices
Art. 1424), both main and secondary switchboards are
installed (see SBTOP audio/video system); for correct
system operation, it will be necessary to activate - on
all switchboards - the setting ”C8.7 - Function main
cps+sec (available from R.I.006)”.
How to configure a main switchboard
1. press the MENU key and use the
keys to view the
8-ADVANCED OPTIONS menu, then press 8;
8-ADVANCED
OPTIONS
2. use the keys to display the 3-TYPE OF
SWITCHBOARD menu, then press 3;
3- TYPE OF
SWITCHBOARD
3. press 2;
1- SECONDARY
*
2- MAIN
The switchboard is configured as SINGLE CPS by default.
It is now possible to configure it as PARALLEL CPS or
SERIES CPS.
f to configure it as 2-PARALLEL CPS, press 2;
1-SINGLE CPS
*
2- PARALLEL CPS
f to configure it as LS-LN, press 1,
to configure it as LP-LN, press 2;
1- LS-IN
2- LP-IN
f to configure it as SERIES CPS, use the keys to
display the 3-SERIES CPS menu, then press 3;
*
3- SERIES CPS
f to configure it as MASTER, press 1,
to configure it as SLAVE, press 2;
1- MASTER
2- SLAVE
How to configure a secondarya switchboard
1. press the MENU key and use the
keys to view the
8-ADVANCED OPTIONS menu, then press 8:
8-ADVANCED
OPTIONS
2. use the keys to display the 3-TYPE OF
SWITCHBOARD menu, then press 3;
3- TYPE OF
SWITCHBOARD
3. Press key 1;
*
1- SECONDARY
2- MAIN
The switchboard is configured as SINGLE CPS by default.
It is now possible to configure it as SERIES CPS, in fact the
function 2-PARALLEL CPS IS NOT AVAILABLE;
*
1- SINGLE CPS
2- PARALLEL CPS
f to configure it as SERIES CPS, use the keys to
display the 3-SERIES CPS menu, then press 3;
*
3- SERIES CPS
f to configure it as MASTER, press 1; to configure it as
SLAVE, press 2;
1- MASTER
2- SLAVE
C8.4 - Self-ignition on/o (available from R.I.006)
This is disabled by default.
This function is only available for non-TOP Simplebus
systems and requires Art. 1259 for the cyclic displaying of
images from remote cameras.
This function can be used to activate or deactivate the self-
ignition transmitted by the internal units with the switchboard
in DAY mode.
To activate the function:
1. press the MENU key and use the
keys to view the
8-ADVANCED OPTIONS menu, then press 8;
8-ADVANCED
OPTIONS
2. use the keys to view the 4 SELF-IGNITION ON/OFF
menu;
4-AUTO ACC.
INTERNA ON/OFF
3. press 4 to activate or deactivate the function;
SERVICE
ACTIVE
SERVICE
NON ACTIVE
