Comelit 6701W - Removing;Fitting the Terminal; Connections

7
Removing/Fitting the Terminal
3
1
2
L L
C
F
P
1
C
F
P
2
1
2
3
Connections
6701W
6701W/BM
6701W/8
1214/2C
VIDEO ENTRY
SYSTEM RISER
VIDEO ENTRY
SYSTEM RISER
P
F
C
LL
P
F
C
FLOOR DOOR CALL
LM
LM
OUT
L
IN
L
IN
L
OUT
L
20 m MAX - Use shielded cable for the connection and do not route the cables in the vicinity of heavy inductive loads
or power supply cables (230V / 400V).
Where multiple door-entry phones or door entry monitors have the same user code, connect the CFP button on one
only; all the devices will ring simultaneously.
