9
Button configuration
Basic configuration
Mini 6701W/8
S2 Dip-switches Mini 6701W - Mini 6701W/BM
DIP 1 DIP 2 DIP 3 DIP 4
A OFF OFF OFF OFF
AP
ACT AI CCS D PAN K
B ON OFF OFF OFF AP CCS AI INT INTb D ACT
C OFF ON OFF OFF AP INT AI INTb ACT CCS CCP
D ON ON OFF OFF AP ACT CCS CCP PAN K D
E OFF OFF ON OFF ACT ACT ACT ACT ACT ACT ACT
F ON OFF ON OFF AP INT ACT CCS CCP INTb PAN
G OFF ON ON OFF AP AI D K CCS CCP INTb
H ON ON ON OFF AP INTb INT AI INT PAN D
I OFF OFF OFF ON AP CCS PAN D AI INTb INTb
J ON OFF OFF ON AP K CCS PAN CCP AI INT
K OFF ON OFF ON AP CCP K PAN ACT INT AI
L ON ON OFF ON AP PAN CCP CCS K ACT D
M OFF OFF ON ON AP INTb AI INT ACT D CCS
N ON OFF ON ON AP INT INT INT INT INT INT
P OFF ON ON ON NULL NULL NULL NULL NULL NULL NULL
ON ON ON ON PROG
default
Legend
AP
Lock-release
Press and release key
ACT Actuator
AI ** Self Activation
CCP * Call to main switchboard
CCS * Call to secondary switchboard
K Caretaker door-entry phone call
PAN * Priority call to switchboard
INT
Intercom call (general programmable or to selective address).
Single-family call default for Kit and Simplebus2
INTb Two-family intercom call - For Kit only
NULL No function
D ** Automatic door opening on receipt of call (Doctor mode) Press and hold key
PROG
With these S2 DIP-switch settings, the buttons control the programmed functions as in “Advanced
configuration”
* Cannot be used in Kit systems
** Pressing and holding enables / disables the function, see“Pressing and holding keys (disabled by default from firmware
version 3.0.1 (3.2.0 for 6701W/8)”
By default the buttons control the functions in A (“Standard configuration” table).
It is possible to change the default configuration of the buttons by changing the positions of S2 DIP-switches 1-2-3-4 on the rear
of the door entry monitor to one of the combinations (B-P) suggested in the table. All the buttons will change function.
