Appendix A - Drawings
In the gure 1 there are the external dimensions for the relay type Buchholz relay:
Figure 4
300 Min
Minimun clearance to remove
the mecanism from the body
15
68
200
25
115
14
M25X1.5
130
152
211.5
156.5
85
