IDENTIFICATION OF COMPONENTS
Refer to gures 1 to 5.
1 - Pump
2 - Petrol/gasoline engines
3 - Frame
4 - Handle
8 - Warning plate
9 - Accessory rack
11 - Water inlet hose-end tting
12 - Water inlet hose clamp
13 - ID plate
14 - Base
15 - Water outlet tting
16 - Water inlet tting
17 - Pressure regulating knob
18 - Pressure indicator
20 - Thermal valve
23 - Water inlet lter
24 - Single barrel nozzle holder head
27 - Oil plug with vent for pump
28 - Petrol / Diesel tank
29 - Nozzle cleaning needle
32 - Spray gun lever safety stop
33 - Spray gun lever
34 - High pressure hose quickt coupling
35 - Lance hose
38 - Pump oil level indicator
41 - Brake
42 - Battery
43 - Ignition key
44 - Gearbox oil level indicator
46 - Oil plug with vent for gearbox
49 - Water inlet lter gasket
57 - Spray gun
58 - Lance knob
59 - High pressure hose
60 - High pressure hose sleeve
61 - Water inlet lter cup
62 - Water inlet lter ring nut
63 - Water inlet lter cartridge
SAFETY DEVICES
• Pressure unloader/regulation valve
Valve, suitably calibrated by the Manufacturer, for regulating work pressure by means of a knob (17)
and that allows the pumped uid to return to pump suction thus preventing the onset of dangerous
pressures when closing the spray gun or when trying to set a pressure that is above the maximum
permitted values.
• Spray gun lever lock device.
Safety stop (32) for locking the spray gun (57) lever(33) in the closed position so it cannot be started
accidentally (Fig. 3, position S).
STANDARD FITTING
Make sure the following are inside the pack of the product you have purchased:
• high pressure cleaner;
• high pressure delivery hose;
• spray gun;
• lance hose;
• bag of accessories with:
- the operating and maintenance manual;
- the engine operating and maintenance manual;
- the declaration of conformity;
- the booklet giving the assistance centres;
- the warranty certicate;
- suction kit with: tting and clamp
- nozzle cleaning needle.
If any problems arise please contact your dealer or an authorised assistance centre.
