correctly and according to current regulations in the country where the water cleaner is installed.
• Total Stop: this stops operation of the water cleaner every time the control lever on the cleaner gun is
released.
• By-pass: means the particular operating mode of the water cleaner that is achieved when the lever of
the cleaner gun is released during normal operation. In this condition, the pressure gauge signals lack
of pressure and the pumped water returns to the suction unit thanks to the pressure control valve.
• Easy Start: this aids starting up the water cleaner by lowering the pressure for the rst moments of its
operation.
F T S
KS 1600 KS 1700
Classic Extra Classic Extra
ELECTRICAL CONNECTION
Mains power supply
230 V - 1~50 Hz 230 V - 1~50 Hz
Absorbed power
2,3 kW 2,7 kW
Fuse
16 A 16 A
HYDRAULIC CONNECTION
Maximum inlet water temperature
50 °C - 122 °F 50 °C - 122 °F
Minimum inlet water temperature
5 °C - 41 °F 5 °C - 41 °F
Minimum inlet water ow
600 l/h - 158 US gph 700 l/h - 185 US gph
Maximum inlet water pressure
0,8 MPa - 8 bar - 116 psi 0,8 MPa - 8 bar - 116 psi
Maximum priming depth
0 m - 0 in 0 m - 0 in
PERFORMANCE
Water ow
480 l/h - 127 US gph 540 l/h - 143 US gph
Maximum pressure
14 MPa - 140 bar - 2031 psi 15,5 MPa - 155 bar - 2248 psi
Recoil of cleaner gun
24 N 25 N
Sound level
75 dB (A) 81 dB (A)
Operator arm vibrations
1,14 m/s2 2,24 m/s2
WEIGHT AND DIMENSION
Lenght x width x height
38 x 32 x 89 cm - 15 x 13 x 35 in
Weight
17 kg - 37 lb 19 kg - 42 lb 17 kg - 37 lb 19 kg - 42 lb
Detergent tank
1,75 l - 0,46 US gal 1,75 l - 0,46 US gal
All features and technical specications are only indications. The Manufacturer reserves the right to modify the appliance as it
deems necessary.
. I C
Please also refer to gures A to D, which are located at the start of these operating and maintenance
instructions.
1. Switch
2. Electrical wire + plug
3. Pressure indicator
4. Detergent tank lling plug (only KS 1700)
5. Water outlet connection (only
CLASSIC)
6. Hose reel (
EXTRA)
7. High-pressure hose
8. Water gun
9. Water gun lever
10. Water gun lever safety lock
11. Lance hose
12. Nozzle-holding multi-adjusting head
13. Knob and hose reel lever (only
EXTRA)
14. Water suction connection
15. Water suction lter
16. Setscrew wrench for nozzle disassembly
17. Pin for nozzle cleaning
18. Technical data plate
19. Room for housing the lance pipe
20. Room for housing the water gun
21. Support to wind the electrical wire
22. Rotojet (only
EXTRA)
25. Water cleaner/hose reel connecting hose (only
EXTRA)
26. Accessory support (only
EXTRA)
27. Caution plate
28. Thermal switch
29. Warning plate
30. Handlebar
