2. Work with Smartphone:
Clip the receiver to the cold shoe mount through the belt clip; Connect the receiver with the mobile phone
through the 3.5mm TRS-TRRS audio cable and pay attention to the access to the audio output jack of the receiver
is the 3.5mm TRS plug, and the access to the mobile phone is the 3.5mm TRRS plug; Insert the headphone to the
3.5 mm TRS/TRRS monitoring port for monitoring
In the absence of a mobile phone holder, the receiver can be
clamped to the mobile phone through the belt clip, and the
installation methods of other accessories are the same as above
TRRS Plug
TRS Plug
3.5mm TRS-TRRS Audio Cable
