Comica BoomX-U - Transmitter (TX) Function and Usage; 1. Power; Low Cut Filter Button; 2. Muting Button

Long press for On/O; Short press for Low Cut Filter
1. Power /Low Cut Filter Button
Long press to switch between normal recording and mute
2. Muting Button
Blue light keeps on after turn on the Transmitter; Purple light keeps on after turn on Low Cut Filter mode; Red light
flicker when pairing transmitter and receiver or low power; Red light keeps on when charging
3. Power /Low Cut Filter Indicator Light
Blue light flicker when sound is input; Red light keeps on when sound is crackled or mute status
4. Audio Status Indicator Light
If there is an abnormal phenomenon such as the device is crash or unable to turn on it, then insert the reset pin
into the reset hole to reset it
5. Reset Hole
Function and Usage
Transmitter (TX)
Function Introduction:
10
