Installation
Transmitter (TX)
1.Use internal microphone :
Adjust the antenna angle; Install the transmitter on the collar through the belt clip so that the internal microphone
points in the direction of the sound source
Internal Mic
Belt Clip
Rotate 180 degrees for the best signal
For better concealment during use, it is recommended that the belt clip be fixed and used outwards
6
