Comica BoomX-U - Components and Instruction (Transmitter TX)

Components and Instruction
Transmitter (TX):
1. Power / Low Cut Filter Button
2. Muting Button
3. Power / Low Cut Filter Indicator Light
4. Audio Status Indicator Light
5. External Mic Locking Buckle
6. 3.5mm TRS Port of External Mic
7. Internal Mic
8. IR Sensor
9. USB-C Charging Port
10. Reset Hole
11. Belt Clip
12. Antenna
5
1
11
2
3
4
6
7
8
9
12
10
4
