COMITRONIC-BTI AMX Series User Manual

9
Contactless safety sensor,
with two potential-free contacts
AMX 3, AMX 4, AMX 5
11. Installation principle with AMX5-MKT for a PLd performance level
Equipment for this installation:
AMX5-MKT: 3
T-Splitter: 2
FMKT: 5 m, 10 m or 15 m
FKT: 5 m, 10 m or 15 m
FKT cord
FMKT cord
T-Splitter T-Splitter
12. Installation principle with AMX3-MKT for a PLd performance level
FKT cord
White Pink
Yellow
Gray
Green
Red
1 6 2 8 4 5 7 3
+
KM1
KM2
3F
Equipment for this installation:
AMX3-MKT: 1
FKT: 5 m, 10 m or 15 m
Inductive loads such as contactors must
be equipped with a voltage limiter (diode,
lter, transil).
Inductive loads such as contactors must
be equipped with a voltage limiter (diode,
lter, transil).
Reduced labor
No possible wiring error
No loss of performance level
feedback
-
+
24V
info
door open
Brown
Blue
White
Pink
Yellow
Gray
Green
Red
2 7 1
6
4 5 3 8
KM1
KM2
3F
24V
24V
testing
info
door open
Cable 50 cm
M12 molded-in
Cable 50 cm
M12 molded-in
NC contact
NC PNP output
