Comm-Tec DaisyNET-TX - Specifications

Page 17 Vers. 1.0
■ Specifications
Operating Temperature Range
0 to +35°C (32 to +95 °F)
Operating Humidity Range
5 to 90 % RH (no condensation)
Input Video Signal
0.5-1.0 volts p-p
Input DDC Signal
5 volts p-p (TTL)
Video Format Supported
HDMI:1080P/1080i/720P/576P/480P/576i/
480i
DisplayPort & VGA: 800x600/1024x768
1280x1024/1400 x1050/1600 x1200/
1920 x1080/1920 x1200
Output Video
HDMI 1.4 + HDCP
Output Audio
DTS-HD, Dolby-HD
Maximum Transmission Distance
100 meters @ CAT-5e/6 AWG 23
Power Supply
5VDC
Power Consumption
11Watts MAX(DaisyNET-TX)
12Watts MAX(DaisyNET-RX)
Dimensions
223mm H×109mm W×27mm D
Mass (Main unit)
1.3Kg (Pairs)
NOTE1: Specifications are subject to change without notice. Mass and dimensions are
approximate.
