Commax DR-2AG/RF1 - Miscellaneous; Part List; Specifications and Features

 52 
32. Miscellaneous
33. Part list
※ Please carefully read this User’s Guide before calling service man After checking the entire
check list, please contact customer service center. We will do our best to make you satisfy
with our services.
Item Description Q’ty
CONN. 2PX300 Wiring Connector 1
CONN.3P(3.96)X250 Wiring Connector 1
CONN.3PX300 Wiring Connector 2
CONN. 4PX300 Wiring Connector 1
CONN. 6PX300 Wiring Connector 2
POWER CORD WHI Adaptor Cord 1
SCREW. FHM
4X40 SUS NI
34. Specifications and Features
Installation Flush Mount Type installation
Model DR-2AG/RF1
UTP Cable(ø 0.5)
Floor Distributor(common 6 wires),
Security station phone(common 4 wires)
Power Source 12V , 1A
Power Consumption Standby : 135mA, Maximum : 320mA
Call Method Handsfree(one way)
Effective Call Range 100m
RF Sensing Range 60mm
Lighting Built-in LED light for night use
Temperature -20°C(tested up to -40°C ) ~ 40°C
Dimensions 130 (W) x 315 (H) x 40 (D) mm
Wiring
Bracket + Flush Mount Bracket
4
