Commodore A 2091-40 - Page 71

Technical
Specifications
D-3
A2091 Card Power Connector
1.0 A Maximum Continuous Current at 12V
2.0 A Maximum Startup Current at 12V
1.0 A Maximum Continuous Current at 5V
Note
that
this
connector
is
designed
to
operate
one
low
power
3.5"
hard
disk
mounted
on
the
card.
Never
connect
a 5.25"
hard
disk,
or
more
than
one
3.5"
hard
disk
to
the
card
as
damage
will
result.
Do
not
install
multiple
A2091
cards
with
card
mounted
hard
disks.
1. +12 VDC
2. ground
3.
ground
(a
4.
+5
VDC
RREN
External SCSI Connector (DB-25)
