MT Series DryLine
®
Dehydrator User Manual
26
Section 8
Specications
SpecicationsforDehydratorMTSeries
Optional items:
System pop-off valve 1/8 NPT 1 PSIG AE01J-0174-009
System pop-off valve 1/8 NPT 2 PSIG AE01J-0174-001
System pop-off valve 1/8 NPT 3 PSIG AE01J-0174-011
Street Tee 1/8 NPT EFTGP-25522
Specications for Dehydrator MT Series
Output Pressure Range nominal 13.79 to 41.37 kPa (2 to 6 psig)
Output Flow Rate (nominal)
MT1000; 28 SLPM (1.0 SCFM)
MT2000; 56 SLPM (2.0 SCFM)
Output Dew Point
better than
-45°C (-50°F) at 92 % RH at +40° C (104° F)
Operating Temperature +1° C to +40°C (+33 to +104 °F)
Low Pressure Alarm 6.7 to Set point Range 201 mbar (0.1 to 0.3 lb/in2)
High Humidity Alarm Fixed 7.5% RH, factory set
Excess Run Alarm Set Range Adjustable 10 to 240 min.
Power Fail Alarm Loss of input power
Alarm Contact Rating Form “C” dry contacts, 1 amps @ 30Vdc
Input Power
240Vac, 50/60Hz,
0.03 Amps Standby
11.5 Amps Running
40 amps starting
(Electrical connections require separate circuits
when multiple dehydrators are installed.)
Output Air Connector 3/8”polytubecompressiontting
Remote Sensing input 3/8”polytubecompressiontting
Dimensions cm (in)
height
114.94 (45.25)
width
41.91 (16.5)
depth
44.45 (17.5)
Weight (net, nominal) kg (lb)
MT1000
58.97 (130)
MT2000
58.97 (130)
Over pressure limit internal 7 psig Pop-off Valve
