5. System Operation
Page 16 PowerShift User Manual Version B
Circuit
1, 2 or 3
LED
Module
“X” LED
Alarm
Condition
(GUI & Relay)
Description
Possible cause Module is over temperature
- Module shuts down affected circuit(s) to protect itself from high temperature
condition
- Possible causes: Module fan intake is blocked, site shelter cooling system has
failed, module fan has failed
- If the problem resolves itself (shelter cooling is restored) and module drops
below threshold, then output power is restored and LED status changes (see
next row below)
Possible cause Input Voltage out of range
- Circuit is shut down due to its input voltage being out of range (see
specification table)
- Possible causes: DC rectifier plant output voltage out of range, DC plant on
batteries that have discharged to a low voltage
- If input voltage is brought back into range the circuit will immediately re-enable
its output
Green
Blink
Yellow
Solid
Major A latent module failure has occurred, circuit was likely previously shut down but
is now providing output power
Possible cause Module was previously over temperature
