J5
G2
G3b
G3a
G4
G2
G2
Loosely tighten all screws until
mount has been fully assembled.
Top of antenna
(red tape)
Mount bracket orientation for mounting antenna
to the left of the support structure
For mounting the antenna to the right of the supporting structure
assemble bracket G4 along with associated plate G2 in position indicated.
G3b
G3a
G4
G4 & G2 position for
left side installation
Page 20 of 30
7722483
SECTION 8
INSTALLATION
INSTRUCTIONS
MOUNT ATTACHMENT AND ALIGNMENT
Carefully lay antenna on clear, flat
ground and remove packing struts..
Do not apply excesive weight to
antennas assembly.
