J2
J2
E
F
G1
Torque to
60Nm
5%
Torque to
60Nm
5%
J2
J2
J4
Torque to 95Nm
5%
J3
Torque to
95Nm
5%
Torque to
95Nm
5%
Torque to
60Nm
5%
Torque M10 screws
(9x) to 38Nm
5%
Page 21 of 30
7722483
SECTION 8
INSTALLATION
INSTRUCTIONS
Mount assembly for mounting antenna
to the left of the support structure
MOUNT ATTACHMENT AND ALIGNMENT
