INS_NetWave_REV– 06/10/13 PAGE 62
INSTALLATION AND OPERATION MANUAL NETWAvE
TECH SUPPORT: 1.888.678.9427
12.3 IPSec
By default, the Internet Protocol Security (IPsec) is disabled for the Netwave Radio boards to
decrease the usage of the CPU resources. It can also be enabled.
The L2TPv3 itself already provides data channel protection against malicious data insertion.
Pre-shared key Sets the password for the IPsec.
12.4 APc SNMP Settings
The “SNMPv3 AP to APC” section contains the APc SNMP settings.
Figure 60: APc SNMP Settings.
Currently, the following default values must be used.
User Name: “admin”
Auth Password: “apc0ntr0ll3r”
Privacy Password: “apc0ntr0ll3r”
12.5 AP SNMP Settings
For communication from the APc to the AP, the settings in the following section of the LuCI web
page is used:
System » SNMP » SNMP Configuration » General Settings
The description of the SNMP options are mentioned in Section "SNMP Configuration."
