COMPA TECH S.r.l.
Web: www.compasaw.com - E-mail: info@compasaw.com
Tel. (+39) 059 527887 - Fax (+39) 059527889
Manuale d’uso
Operator’s handbook
Mode d’emploi
- 27 -
3. TECHNICAL INFORMATION
3.1 Use of the machine
The cutting-off machine FC 300 RAP / FC 350 RAP can
only be used to saw wood, aluminium and PVC using
the special blades.
Any other use not described in this manual can be
dangerous for the user, as well as damage the device.
CAUTION! If certain machine parts are
damaged or missing, do not connect the
power supply cable and switch it on until
the device is intact and complete.
CAUTION! Do not let familiarity with fre-
quent use become supercial. Always re-
member that even the slightest distraction
can cause serious injury.
3.2 Technical features
Power supply:
230 V
Rated frequency:
50 Hz
Rated power:
1800 W
Blade rpm:
3000 rpm
Blade diameter:
FC 300 RAP: 300 mm
FC 350 RAP: 350 mm
Blade hole diameter:
20 - 30 mm
Dimensions:
FC 300 RAP: 81x50x60 cm
FC 350 RAP: 81x54x65 cm
Weight:
FC 300 RAP: 36 kg
FC 350 RAP: 45 kg
Maximum cutting dimensions:
FC 300
RAP
FC 350
RAP
Horizontal cut
132 mm
121 mm
160 mm
45° horizontally tilted cut
99 mm
96 mm
110 mm
Vertical cut
59 mm
75 mm
100 mm
45° vertically tilted cut
59 mm
75 mm
100 mm
3.3 Noise levels
The average sound pressure level, Lm, on the
test surface, measured in accordance to the DIN
45635 - 1658 standard, is 81dB (A).
The sound power level, Lw, measured in accord-
ance to the DIN 45635 - 1658 standard, is 96.2
dB (A).
The weighted root-mean-square value of hand -
arm acceleration frequency does not exceed 2.5
m/s2.
3.4 Vibrations
Since the machine is afxed to a special support,
there is no risk of transmitted hand-arm vibrations.
3.5 Description of the machine and
accessories
List of machine parts (Fig. 2):
1. Support table
2. Turntable
3. Saw-motor arm
4. Supporting rulers
5. Blade
6. Inner blade guard
7. Handgrip
8. Motor
9. Fixed blade guard
10. Cutting register (full)
11. Belt guard
List of separate components supplied with the machine:
Instruction handbook
Set of wrenches for maintenance
Piece pusher for small pieces
Declaration of conformity
Stop rod
Optional equipment:
Roller support
Automatic aspirator
Fixed support bench
Vertical vice
