11. Setting up the C4000
Once the pump is connected on site, the final setup check and calibration to complete the
installation must be carried out, using the Parameter Switch and Calibration (K-Factor) Switch.
These switches are found on the C4000 Microprocessor Board which is housed in a metal
enclosure located on the left front of the unit below the display panel
11.1 Configuration Codes
The configuration code has been set at Compac and should not be changed
In the event of iit being lost and having to be re-entered the configuration is written on the
yellow label on the C4000 processor board cover.
11.2 Parameter Switch Settings
11.2.1 Setting the Pump Number
This must be set at the pump, for each hose, so that communications with
a controller can take place. The location of this switch is shown in the
diagram below.
Depress the Parameter Switch nine (9) or more times until the message
'PnA XX' appears in the litres display window. When the switch is
pressed again 'Pnb XX ' will appear on the display. These two options
will toggle each time the switch is pressed. To alter either of the pump numbers, press and hold
the Parameter Switch when the pump number to be altered appears on the display. This number
will then increment. The switch should be released when the desired pump number is displayed.
The value of the displayed number will then be stored in the C4000 memory as the pump
number for that hose.
NOTE: For a single hose only ‘Pn” will appear
11.2.2 Setting the Price
Using the Parameter Switch, follow the chart to set the price for the hose(s) in question.
Step
ACTION
RESULT
1
Ensure that the nozzle is hung up
Dispenser in idle state
2
Press and Hold the Parameter switch until the
“Price per litre” is displayed.
The price for side ‘A’ is shown as ‘PX.XXX’ on the
litres display and ‘PrA’ is displayed on the money
display.
3
Press and hold the Parameter switch.
A digit, of the displayed ‘Price per litre’, will begin to
increment.
4
When the digit is correct, release the Parameter
switch.
5
Repeat steps 3 and 4 for each digit of the ‘Price per
litre’.
NOTE: the C4000 will reset itself if the Parameter
switch is left for more than 60 seconds.
Continue for Dual hose units
6
Press and release the Parameter switch 8 or more
times in quick succession
The price for side ‘B’ is shown as ‘PX.XXX’ on the
litres display and ‘Prb’ is displayed on the money
display.
7
Repeat steps 3 to 5 above.
