17. MR40P MR80P Spare Parts
Commercial display
(as shown - includes backlighting)
F-CP-DISPLAY-CMH
Retail display (includes
backlighting)
F-CP-DISPLAY-GD1H
Tote
F-BA-TOTE-A-K
C4000 microprocessor board
F-CP-C4PROCES-A
Nozzle holder
F-NOZL-HLDR-M5SR
COM50 meter
(complete)
F-METER-COM50-WPE2
COM50 meter
(electronics only)
F-METER-50ESP2
3/4 HP electric motor
F-MOTOR-230-550W
Solenoid (complete)
F-SOLND-S20-2P1X
Pump unit
F-PUMP-ZYB-50-40 (for 40 lpm only)
F-PUMP-ZYB-50 (for 80 lpm only)
(includes inlet and outlet gaskets)
C4000 power supply
(does not include box)
F-CP-C4PWR-ASSEM
Motor triac
F-AT-BTA40-RD91 Solenoid service parts
Coil - F-SOL-20P1-COIL
Also (not shown) Main body kit - F-SOL-20P1-MBKT
Track 2 cardreader Top body kit - F-SOL-20P1-
F-BA-CARDRD-T2C4M
Preset (fascia with membrane keypad & interface PCB)
F-FAS-PSET-MEM
Always quote model and serial number when ordering spare parts.
