19
COMPRESSOR CONFIGURATION MODELS
(FACTORY PRESET PARAMETERS)
TABLE B
Unload
Blow Time Design Run Starts
Y/D Down Before P P P Press. on Accel. per Max.
Model Time Time Stop Load Unload Max Limit Time Time Hour Temp
1 2.0 10 10 90 100 125 110 15 3 4 230
2 4.0 10 10 90 100 125 110 5 2 8 230
3 1.0 10 10 90 100 125 110 5 2 8 230
4 2.0 10 10 100 110 135 120 15 3 4 230
5 4.0 10 10 100 110 135 120 5 2 8 230
6 1.0 10 10 100 110 135 120 5 2 8 230
7 2.0 10 10 115 125 150 135 15 3 4 230
8 4.0 10 10 115 125 150 135 5 2 8 230
9 1.0 10 10 115 125 150 135 5 2 8 230
10 2.0 10 10 140 150 175 160 15 3 4 230
11 4.0 10 10 140 150 175 160 5 2 8 230
12 1.0 10 10 140 150 175 160 5 2 8 230
