8. Control system
39
8.10 Menu structure (apart from L07RS-L11RS) (values are examples)


+


INPUT 1: OFF
:
OUTPUT 1: FAULT
OUTPUT 2: OFF
DESIGN PRESS 13.0bar
START ProTECT 0.8bar
HEAVY STARTUP 3.5bar
FINAL TEMP WARN 110°C
FINAL TEMP MAX 120°C
MIN START TEMP 1°C
RUN-ON TIME 90s
SOFT STOP 30s
STAR/DELTA TIME 6s
SOFTWARE: DPro-L-x.xx
TH 08.02.07 13:55:41
1 ____________ 00:00 00:00
:
7 ____________ 00:00 00:00
:
p
2
1 __________ 00:00 00:00
:
p
2
7 __________ 00:00 00:00
02!EM-STOP 12345h
01!EM-STOP 12300h
:
:
CUT-OUT POINT 13.0bar
CUT-IN POINT 12.5bar
p
2
CUT-OUT POINT 10.5bar
p
2
CUT-IN POINT 10.0bar
AUTOMATIC OPERATION
ENABLE REMOTE-START OFF
TIMER CONTROL OFF
p
2
TIMER CONTROL OFF
AUTO RESTART OFF
POWER LOSS TIME 2s
START-UP DELAY 5s
DRYER PRE-RUN 0min
RS485-ProTOCOL ModBus
RS485-BAUDRATE 19200
RS485-ADDRESS 1
[MAINTENANCE SCHED.]
[ TIMER CONTROL ]
[ FAULT MEMORY ]
[ CONTROL MENU ]
[OPTIONAL IN-/OUTPUTS]
[ LIMIT VALUES ]
TOTAL RUNNING 12345h
LOADED HOURS 10987h
AIR FILTER IN 2000h
OIL FILTER IN 2000h
SEPARATOR IN 4000h
OIL CHANGE IN 4000h
SHUTDOWN OFF










+




+
















+












+












+








+






