11. Annex
59
11.7 Technical data USA/Canada version L11RS
Technical data 50Hz / 60Hz
L11RS
Maximum operating pressure
psi g
186
Minimum operating pressure
psi g
73
Ambient temperature
°F
+ 34 / + 113
Operating pressure
psi g
110
130
145
190
min.
max.
min.
max.
min.
max.
min.
max.
Flow
cfm
22.1
63.8
21.5
58.8
22.6
55.2
20.1
44.7
After-cooler outlet temperature above ambient temp.
°F
25
Sound pressure level (to ISO 2151)
dB(A)
70
Nominal motor rating
hp/ kW
15 / 11
Voltage (frequency)
V
460V[+/-10%] (60 Hz)
Full-load current max. at 460V
Amps
24
Motor protection type
TEFC (IP55), EPAct
Nominal speed
rpm
1096...2950
Nominal fan motor power
no separate fan motor
Recommended cable size at 460V ; @ 167 °F
AWG
10
Recommended fuse rating at 460V, time delay
Amps
30
Cooling air outlet temperature above ambient temp.
°F
36
max. allowable pressure drop in duct at ambient
Pa
130 @ 95 °F / 70@ 113 °F
Total oil volume
gal (Litres)
1.3 (5)
Compressed air delivery connections
3/4" - 14 NPT
Weight
lbs (kg)
509 (231)
Dimensions L x W x T
inch (mm)
26.5 x 24.8 x 41.3 (667 x 630 x 1050)
