11. Annex
55
11.3 Technical data EUROPE version L07RS
Technical data 50Hz / 60Hz
L07RS
Maximum operating pressure
bar
13.0
Minimum operating pressure
bar
5.0
Ambient temperature
°C
+ 1 / + 45
Operating pressure
bar
7.5 bar
9 bar
10 bar
13 bar
min.
max.
min.
max.
min.
max.
min.
max.
Flow
m
3
/min
0.48
1.26
0.46
1.10
0.44
1.01
0.41
0.83
After-cooler outlet temperature above ambient temp.
°C
13
Sound pressure level (to ISO 2151)
dB(A)
69
Nominal motor rating
kW
7,5
Voltage (frequency)
V
380V[+10% -5%];400V[+/-10%]; 460V[+/-10%]
(50, 60Hz)
Full-load current max. (380V/400V/460V)
A
22 /21 /18
Motor protection type
IP55, IE 2
Nominal speed
rpm
1256...2950
Nominal fan motor power
kW
no separate fan motor
Recommended cable cross-section (380V/400V/460V)
mm
2
4G4 /4G4 /4G4
Recommended fuse size (380V/400V/460V)
A
25 / 25 / 20
Cooling air flow through ventilator
m
3
/min
25
Cooling air outlet temperature above ambient temp.
°C
18
Max. allowable pressure drop in duct at ambient
35°C/45°C
Pa
110 / 90
Total oil volume
l
5
Compressed air delivery connections
---
EN 10226 Rp 3/4" (DIN 2999-Rp 3/4)
Weight
kg
222
Dimensions L x W x H
mm
667 x 630 x 1050
