NOTE: Based on extensive experience and a medium-hard coffee blend, we
recommend replacing the burrs following the quantities in next table:
Steel Red Speed Lucidate
E5 OD 250 Kg
E6 OD 300 Kg 2,250 Kg
E8 OD 800 Kg 5,000 Kg
E10 CONIC OD 1,200 Kg 8,000 Kg
E10 MASTER CONIC OD 1,200 Kg 8,000 Kg
12.3. Grinding group maintenance
Not following the recommended burr life guidelines can compromise the safety of
the grinder.
These operations should be done by a qualied service tecnician.
To perform grind chamber maintenance please observe the following steps:
Turn off the grinder by making sure the main power switch ( ) is on the OFF
position. Disconnect the plug from the power source. Loosen the hopper security
screw ( ) using a flat head screw driver as seen in Fig.2 and remove the hopper
( ) from the grind regulator ( ). Loosen the screws on the grind regulator ( )
using a Torx T20 screw driver following Fig.10.
