12.3. Silicon curtain replacement (F8 model)
The silicon curtain ensures consistency in the dose and reduces static electricity.
Located inside the coffee outlet ( ), it can be replaced by following the steps below:
1. Remove the grind regulator control knob ( ) loosening the xing bolt with an
Allen key No. 2.5.
2. Remove the four screws securing the cover using an Allen key No. 2.5.
3. Remove the four screws xing the base of aluminum siding, using an Allen key
No. 2.5.
4. Remove the coffee outlet ( ), by removing the two retaining screws using an
Allen key No. 2.5 At this point, access to the silicon curtain is possible. Replace
the silicon curtain with a new silicon curtain of different thicknesses according
to the needs of each coffee. Simply remove the screw curtain using a #10 Torx
wrench.
