8. REGULATION
8.1. Adjusting the lower portalter support
In order to ensure the proper distribution of ground coffee in the portalter, while
supporting the portalter in a hands-free position during dosing, it is possible to
adjust the height of the lower portalter support ( ).
1. Loosen the two adjustment screws ( ) found on each side of the upper
portalter fork ( ), by using the Allen Key included with your grinder.
2. Adjust the support to the desired height using the portalter as the point of
reference.
3. Tighten the screw ( ) found on each side of the upper portalter fork ( ), with
the Allen Key provided (Fig. 1).
NOTE: If the adjustment is extreme (too high or too low), difculties in operating
the dosis button might occur.
