Compak K3 - Coffee Serving Quantity Regulation

ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 | v. 22/09/2014 | K01068
12
NOTE: If the output is very slow, it could mean that the coffee is being ground too
ne.Iftheoutputisveryfast,itcouldmeanthatthecoffeeisbeinggroundtoo
coarse. A perfect espresso grind is found when the grind point gives an infusion of
25 ml of coffee in 25 seconds using 7 grams of ground coffee.
8.3.Regulatingthecoffeeserving
The dispensers are factory adjusted to serve an amount of approximately 7 gr of
ground coffee, but this quantity can be regulated between 6 and 10 gr, as follows:
1. Remove the ground coffee dispenser lid ( ) and turn the dispensing regulation
screw ( ) clockwise to obtain a smaller amount of coffee, and counterclockwise
to obtain a larger amount (Fig. 6).
2. Once the quantity of eachserving has been regulated, replace the ground coffee
dispenser lid ( ).
