16 Upgrade Guide
Upgrading and Replacing Hardware
5. Lift the processor socket lever and remove the old processor.
Carefully insert the new processor, then lower the lever back into
place while pressing lightly down on the processor to ensure that
it seats properly.
Ä
CAUTION: Insert the processor carefully, making sure that the orientation
is correct. It can go in one way only; do not apply excessive force.
6. Remove all old thermal interface material from the underside of
the heatsink by using the alcohol wipe that is provided with the
processor kit.
7. Squeeze the contents of the thermal grease syringe onto the top of
the processor.
8. Place the heatsink on top of the processor.
