Compaq UPS R3000 XR - Page 14

Illustrated Parts List
2-3
Table 2-1
UPS Spares Parts List
Ref Description Spares Part #
1
UPS Chassis **
2
Front Bezel 204507-001
3
Electronics Module (low voltage)
Electronics Module (high voltage)
204506-001
216097-001*
4
UPS Battery Pack 204503-001
5
Battery Bracket **
6
X-Slot Serial Board 204514-001
7
UPS L530-NA
UPS L530-JP
UPS 620H-NA
UPS DTC-INTL
UPS 309-EURO
222383-001*
222383-291*
222384-001*
222385-002*
222386-021*
8
Cord Retention Clip 204505-001*
9
Front and Rear Mounting Brackets 204504-001*
-
Mounting Rail 322578-002*
q
Maintenance and Service Guide 223932-001*
Cables
w
UPS to server interface cable 204508-001*
e
UPS to UPS interface cable 204509-001*
* Not shown
** No spare available
