Compaq UPS R3000 XR User Manual

Specifications
5-3
Output Specifications
Table 5-3
Output Specifications
UPS Model Effective VA Nominal Power
Rating (W)
Load Segment # Output
Receptacles
R3000 XR-NA 2880 2700 1 2 x 5-15R
1 x L5-30R
2 2 x 5-15R
3 2 x 5-15R
R3000j XR-JPN 2400 2250 1 2 x 5-15R
1 x L5-30R
2 2 x 5-15R
3 2 x 5-15R
R3000h XR-NA 3000 2700 1 3 x IEC-320, C13
1 x L6-20R
2 3 x IEC-320, C13
3 3 x IEC-320, C13
R3000h XR-JPN 3000 2700 1 3 x IEC-320, C13
1 x L6-20R
2 3 x IEC-320, C13
3 3 x IEC-320, C13
R3000e XR-INT 3000 2700 1 3 x IEC-320, C13
1 x IEC-320, C19
2 3 x IEC-320, C19
3 3 x IEC-320, C13
R3000i XR-EURO;
R3000i XR-SCHUKO;
R3000i XR-SA
3000 2700 1 3 x IEC-320, C13
1 x IEC-320, C19
2 3 x IEC-320, C13
3 3 x IEC-320, C13
